VOTOL EM-70 controller
These Controllers pack a huge punch in torque and power while keeping the reliability needed for all applications from motor bikes to large quad copters , Electric cars, Buggy , scooters go-kart and many more applications. These are hands down the one of the best controller on the market. We use and carry the Em-100 and Em-70 in stock. but also can order in the whole VOTOL range for your required project. These can also be customised via an optional cable to code these to optimise even further. We can also pre set the required parameters.
Please note these controllers do not come with programming cable - this can be ordered separately along with software download.
Harness pictured comes standard with all controllers
*** The default program is optimised and can be used without programming. ***
We also offer tech support for these controllers when ordered through our store
Product description
Model: EM70 ECU sine wave controller
1. Available Battery Voltage: 48V-72V
2. Max DC current: 70A
3. Boost DC current: 85A
4. Peak Phase current: 230A
5. Max. Power: 3640W
6. Mosfets Detail: 18 FET
7. Matched Motor Rated Power: 1KW-2.5KW
8. Max. Efficiency: 88%~93%
9. Degree of Waterproof: IP67
10. Flux Weaking Ratio: 100~250%
11. Certification: CE, CCC
12. Working Communication: Hall Sensor
13. Net weight: 1150g
14. Size: 218mm *124mm * 52mm
15. Support Programmable by PC
